DevicesEV charging station
Alfen charging stations
This guide will serve as a guide to adjust the Alfen charging station settings to allow communication with and control by the SmartgridOne Controller. For more in depth information you can use the
Supported Devices
| Device Type | Modbus TCP (Ethernet) | RS485 |
|---|---|---|
| Most Alfen charging stations | ✅ | ❌ |
Configuration
Install the charging station.
-
Update the Alfen charging station to firmware version 4.2.0 (or higher).
-
Connect the Alfen charging station to a network with the following requirements:
